Product information "Intercooler Hyundai Veloster 1.6TGDi Wagner Competition kit"
Hyundai Elantra Sport, GT-Line, GTS 1.6TGDI 150KW/204HP 2017+
Hyundai Veloster Turbo 1,6TGDI 150KW/204HP 2018+
The WAGNERTUNING high performance intercooler has a new Competition - net (Tube Fin) with the dimensions of
580 mm x 120 mm x 150 mm + 580 mm x 62 mm x 70 mm (stepped net: 12.96 liters), which was developed specifically for the demands of the Kia (Pro)Ceed GT. This high performance mesh thus offers a 60% larger flow area, as well as 118% more mesh volume compared to the original intercooler.
The cast aluminum end boxes were designed in CAD and optimized using CFD simulations (for ideal internal airflow). The result is excellent cooling properties at lowest backpressure. In addition, the newly developed Competition high-performance mesh still provides sufficient airflow to the adjacent components, such as the water cooler, through the use of a specially manufactured air baffle. Thus, this kit is just right for racing. An optimal cooling of the charged air with a significant increase in performance!
An anti-corrosion coating with excellent heat conduction properties protects the WAGNERTUNING intercooler from any environmental influences, as a result of which a lasting and optimal cooling effect can be guaranteed. The assembly takes place at the original mounting points and is easy to perform (plug and play). All our products are subject to constant qualitative monitoring.
Inlet and outlet diameter: Ø65mm
OEM intercooler:
V = 5,94 L
A = 660 cm²
WAGNERTUNING intercooler:
V = 12,96 L (+118%)
A = 1055 cm² (+60%)
Scope of delivery:
1 intercooler
2 silicone hoses
1 air baffle
1 mounting material
1 installation instruction
Login
Manufacturer Info
WAGNER Intercoolers zijn leverbaar als Performance en Competition. Het verschil zit in het type gebruikte gaas. Bij de Performance is dat "Bar & Plate" en bij de Competition "Tube Fin".
Daarnaast zijn er nog 3 verschillende volumes: EVO1, EVO2 en EVO3.
EVO1 is ontwikkeld om gebruikt te worden in combinatie met de originele turbolader met als resultaat een zeer efficiënte koeling van de inlaatlucht. EVO2 en EVO3 hebben een grotere volume en gaan prima samen met de toename van inlaatlucht na een turbolader upgrade. Afhankelijk van het systeem worden ook de in- en uitlaat diameters vergroot.
Deze intercoolers worden met de benodigde siliconen slangen geleverd.
