Product information "Intercooler Volkswagen Polo AW 2018-GTI 2,0TSI Wagner Competition kit"
COMPETITION CHARGE AIR COOLER KIT for VW Polo AW GTI 2,0TSI ( 147KW/200HP) from 2018.
The WAGNERTUNING high-performance charge air cooler features a new type of Competition mesh (Tube Fin) with dimensions of 600 mm x 167 [101] mm x 125 [90] mm [stepped]. This corresponds to an external net volume of 11.14 liters. Thus, the WagnerTuning Competition intercooler for the Polo GTI offers a 24% larger frontal inflow area and 73% more external net volume compared to the original intercooler.
The cast aluminum end boxes were designed in CAD and optimized using CFD simulations (for ideal internal airflow). The result is excellent cooling characteristics with the lowest back pressure. Thus, this kit is just right for racing. An optimal cooling of the charged air with a significant increase in performance!
An anti-corrosion coating with excellent heat conduction properties protects the WAGNERTUNING intercooler from any environmental influences, as a result of which a lasting and optimal cooling effect can be guaranteed. The assembly takes place at the original mounting points and is easy to perform (plug and play). All our products are subject to constant qualitative monitoring.
Inlet diameter Ø60 mm ; outlet diameter Ø60 mm
OEM intercooler:
700 mm x 115 mm x 80 mm
V = 6,44 L
A = 805 cm²
WAGNERTUNING intercooler:
600 mm x 167 [101] mm x 125 [90] mm [stepped]
V = 11,14 L
A = 1002 cm²
Scope of delivery:
1 intercooler
2 silicone hose
1 mounting material
1 installation instruction
Login
Manufacturer Info
WAGNER Intercoolers zijn leverbaar als Performance en Competition. Het verschil zit in het type gebruikte gaas. Bij de Performance is dat "Bar & Plate" en bij de Competition "Tube Fin".
Daarnaast zijn er nog 3 verschillende volumes: EVO1, EVO2 en EVO3.
EVO1 is ontwikkeld om gebruikt te worden in combinatie met de originele turbolader met als resultaat een zeer efficiënte koeling van de inlaatlucht. EVO2 en EVO3 hebben een grotere volume en gaan prima samen met de toename van inlaatlucht na een turbolader upgrade. Afhankelijk van het systeem worden ook de in- en uitlaat diameters vergroot.
Deze intercoolers worden met de benodigde siliconen slangen geleverd.
