Intercooler Subaru Impreza WRX STi 2014- Wagner Competition Kit
Subaru WRX Sti 2,5 Turbo 221KW/300HP (2014-)* Not suitable for vehicles with strut brace. The Competition high-performance intercooler has the following net dimensions (530mm x 205mm x 95mm= 10,300cm³) and thus offers a 20% larger inflow area and 86% more charge air volume compared to the original intercooler. A new type of Competition high-performance mesh (Tube Fin) is used here, which was developed directly for the demands of the Subaru WRX STi. The cast aluminum end boxes were created in CAD and optimized for the best possible internal airflow using CFD simulations. The intercooler inlets and outlets were not modified. The intercooler back pressure is identical to the stock intercooler. An anti-corrosion coating with heat conduction properties protects our intercoolers from environmental influences. This guarantees permanent and optimal cooling with a significant increase in performance. Installation is done by replacing the OEM intercooler and is easy to perform (plug and play). All our products are subject to constant qualitative monitoring. Dimensions original intercooler:530mm x 170mm x 61,5mmV=5,54 litersA=901 cm² Dimensions WAGNERTUNING intercooler:530mm x 205mm x 95mmV=10,30 LiterA=1086 cm² Scope of delivery:1 intercooler (black coated)1 air duct1 silicone hose (black)1 mounting material1 assembly instruction Not approved in the area of the STVO.
Intercooler Subaru Impreza WRX STi 2002-2005 Wagner Competition Kit
Subaru WRX Sti GD C?E 2,0 Turbo 195KW/265HP (2002-2005) RHD*only plug and play suitable for RHD vehicles dimensions original intercooler:475mm x 185mm x 60mmV=5,27 literA=878,75 cm² Dimensions WAGNERTUNING intercooler:530mm x 205mm x 95mmV=10,3 LiterA=1086 cm² Scope of delivery:1 intercooler (black coated)1 air guide2 silicone hose (black)1 mounting material1 assembly instruction Not approved in the area of the STVO.
Intercooler Subaru Impreza WRX STi 2007-2013 Wagner Competition kit
Subaru WRX Sti 2.5 Turbo 221KW/300HP (2007-2013). * Not suitable for vehicles with strut brace. The Competition high performance intercooler has the following net dimensions (530mm x 220mm x 95mm= 11,08L) and thus offers a 30% larger inflow area as well as 100% more charge air volume compared to the original intercooler. A new type of Competition high-performance mesh (Tube Fin) is used here, which was developed directly for the demands of the Subaru WRX STi. The cast aluminum end boxes were created in CAD and optimized for the best possible internal airflow using CFD simulations. The intercooler inlets and outlets were not modified. The back pressure of the intercooler is identical to the standard intercooler. An anti-corrosion coating with heat conduction properties protects our charge air coolers from environmental influences. This guarantees permanent and optimal cooling with a significant increase in performance. Installation is done by replacing the OEM intercooler and is easy to perform (plug and play). All our products are subject to constant qualitative monitoring. Dimensions original intercooler:530mm x 170mm x 61,5mmV=5,54 litersA=90,100 mm² Dimensions WAGNERTUNING intercooler:530mm x 220mm x 95mmV=11,08 LiterA=116.600 mm² Scope of delivery:1 intercooler2 air guide plate1 silicone hose1 mounting material1 assembly instruction
