Intercooler Audi TT 8S 2014- 2.0 TFSi Wagner Competition kit

WA200001048d

TT [8S] 2.0 TFSI 169kw/230HP 2014- The Competition intercooler has the following net dimensions (640mm x 410mm x 65mm) and thus has 17 liters of external charge air volume (OEM 9 liters). The newly developed Competition high-performance mesh (Tube Fine) still provides sufficient airflow to the adjacent components, such as the water cooler, and is also very light. The intercooler has a total weight of only 8.9kg. The cast aluminum end boxes were created in CAD and optimized for the best possible internal airflow using CFD simulations. An air guide integrated in the end box allows a homogeneous filling of the Competition high performance mesh. The intercooler's inlets and outlets were enlarged to Ø 70mm, so this kit comes with reinforced silicone hoses. Overall, this intercooler has far less back pressure than the stock intercooler. In addition, all our intercoolers have an anti-corrosion coating with heat conduction properties. This guarantees permanent and optimal cooling with a significant increase in performance. The assembly is done by replacing the OEM intercooler and is easy to perform. All our products are subject to constant qualitative monitoring. The WAGNERTUNING Competition intercooler kit for the VAG 1,8TSI - 2,0TSI engine is suitable for the following vehicles: With further modifications (see notes) on the vehicle, also suitable for:- Audi TT 8S 2.0TFSI 169KW / 230HP*.- Audi TTS 8S 2.0TSI 228KW/310HP* Due to the additional adjustments, the installation effort increases to a total of about 5-6Std: Scope of delivery:1 intercooler2 silicone hoses2 hose clamps1 mounting material1 assembly instruction

€996.00

Intercooler Audi TTRS [8J] 2.5L Competition kit Evo 3.X voor upgrade 600PK+

WA200001056.X

TTRS 8J 250KW/340HP (2009-2014)TTRS plus 8J 265KW/360HP (2009-2014) The intercooler kit EVO3 for the Audi TTRS 8J is a further development of the previously known EVO2 intercooler kit. The high performance intercooler has the following net dimensions (515mm x 367[274]mm x 95mm), providing a 120% larger flow area and 142% more charge air volume compared to the original intercooler. The newly developed Competition high-performance mesh grants sufficient airflow to the adjacent components, such as the water cooler, and is also very lightweight. The end boxes of the charge air cooler are made of cast aluminum and were optimized under flow analyses in the CAD system. With the help of incorporated air baffles, in the entrance, is ensured a uniform filling of the intercooler. The result is excellent cooling properties with minimal back pressure. Thus, this kit is exactly the right thing for racing. The intercooler and the original crossmember form a stable unit and weighs only 11.2kg thanks to the new Competition high-performance mesh. The assembly is done at the original mounting points and is easy to perform(1:1 exchange). An optimal cooling of the charged air with a significant increase in performance! The connection diameter is 68mm on both sides. OEM intercooler: cooling surface 856cm² / charge air volume 6,8LWT EVO 1 Performance: cooling surface 856cm² / charge air volume 9,4LWT EVO 2 Competition: cooling surface 1391cm² / charge air volume 13,2LWT EVO 3 Competition: cooling surface 1890cm² / charge air volume 16,5L All our products are subject to constant qualitative monitoring. Scope of delivery:1 intercooler together with the cross bar1 mounting material1 set of license plate holder1 installation instruction

€1,708.00

Intercooler Audi TTRS [8J] 2.5L Wagner Competition kit Evo 1

WA200001107b

Audi RS3 8V Sportback 270KW/367HP 04/2015?04/2016Audi RS3 8V Sportback/Sedan 294KW/400HP 08/2017+Audi TTRS 8S 294KW/400HP 11/2016+ The Competition high performance intercooler has the following net dimensions (660x180x110 = 13,070cm³), providing a 14% larger flow area, as well as 57% more charge air volume compared to the original intercooler. The Competition high performance mesh is a high quality Tube Fin mesh with internal turbulators. Despite its size, the total weight of the intercooler is only 8.3kg. The end boxes of the intercooler are made of cast aluminum and have been optimized using flow analysis in the CFD system. The result is excellent cooling properties with the lowest backpressure. In addition, all our charge air coolers have an anti-corrosion coating with heat conduction properties. This guarantees permanent and optimal cooling with a significant increase in performance. Complete ready-to-install kit, simply replace with stock intercooler - plug and play. Tested and pressure stable up to 6 bar. All our products are subject to constant qualitative monitoring. Suitable for racing. Dimensions original intercooler:640mm x 163mm x 80mmV=8,3 litersA=1043 cm² Dimensions WAGNERTUNING intercooler:660mm x 180mm x 110mmV=13,07 LiterA=1188 cm² Scope of delivery:1 intercooler (black coated)1 assembly instruction

€1,037.00

Intercooler Audi TTRS [8J] 2.5L Wagner Competition kit Evo 2

WA200001024

TTRS 8J 250KW/340HP (2009-2014)TTRS plus 8J 265KW/360HP (2009-2014) Intercooler Upgrade Kit EVO 2 for Audi TTRS 8J The high performance intercooler has the following net dimensions (535mm x 260mm x 95mm), providing a 62.5% larger flow area and 94% more charge air volume compared to the original intercooler. The newly developed Competition high-performance mesh grants sufficient airflow to the adjacent components, such as the water cooler, and is also very lightweight. The end boxes of the intercooler are made of cast aluminum and were optimized under flow analyses in the CAD system. This intercooler has hevorragende cooling properties and is just right for racing. The intercooler and the original crossmember form a stable unit and weighs less than 10kg thanks to the new Competition high-performance mesh. The assembly is done at the original mounting points and is easy to perform(1:1 exchange). An optimal cooling of the charged air with a significant increase in performance! All our products are subject to constant qualitative monitoring. Scope of delivery:1 intercooler together with the crossmember1 set of license plate holder Remark:special coatingfor racing

€1,505.00

Intercooler Audi TTRS [8J] 2.5L Wagner Competition kit Evo 3

WA200001056.S

€1,515.00

Intercooler Audi TTRS [8J] 2.5L Wagner Competition Kit Gen.2 EVO1

WA200001019a

Product video: http://www.youtube.com/watch?v=JGpgXoWxs3c&feature=youtu.be The revised Competition Gen.2 intercooler kit EVO1 for Audi TTRS 8J and RS3 8P 2,5TFSI. The high performance intercooler has the following external mesh dimensions (535mm x 160mm x 110mm), providing 40% more charge air volume compared to the original intercooler. The newly developed Competition high-performance mesh offers the highest cooling properties at the cutting edge of tube-fin technology. The weight of the intercooler is 6.7kg. CAD designed freeform cast aluminum end boxes for best possible internal airflow. Overall this intercooler has far less back pressure than the stock intercooler. In addition, all our intercoolers have an anti-corrosion coating with heat conduction properties. This guarantees optimal cooling with a significant increase in performance. The installation is done by replacing the OEM intercooler - plug & play - the original intercooler hoses can still be used. All our products are subject to constant qualitative monitoring. The Competition Gen.2 Intercooler Upgrade Kit EVO 1 fits the following vehicles. Audi TTRS 8J 250KW/340PS (2009-2014)Audi TTRS plus 8J 265KW/360PS (2009-2014)Audi RS3 8P Sportback 250KW/340PS (2011-2013) Scope of delivery:1 intercooler1 assembly instruction

€600.00

Intercooler Audi TTRS [8S] 2.5L Wagner Competition kit Evo 3

WA200001136.S

TTRS [8S] 2.5L TSI 294KW/400HP 05/2016- The high performance intercooler has the following net dimensions (515mm x 367mm x 95mm [stepped] = 16,500cm³), providing an 84% larger flow area, as well as 101% more charge air volume compared to the original intercooler. The newly developed Competition high-performance mesh grants sufficient airflow to the adjacent components, such as the water cooler. It is a high quality Tube Fin mesh with internal turbulators. The end boxes of the charge air cooler are made of cast aluminum and were optimized under flow analyses in the CFD system. With the help of incorporated air baffles, in the inlet, a uniform filling of the intercooler is ensured. The result is excellent cooling properties with minimal back pressure. Thus, this kit is suitable for racing. In addition, all our intercoolers have an anti-corrosion coating with heat conduction properties. This guarantees permanent and optimal cooling with a significant increase in performance. The intercooler and the original crossmember form a stable unit and weighs, thanks to the new Competition high-performance mesh, only 11.7kg. The installation is done at the original mounting points and is easy to perform (see installation instructions for slight adjustments). Tested and pressure stable up to 6 bar. All our products are subject to constant qualitative monitoring. OEM intercooler:Cooling surface 1024cm² / charge air volume 8,2LInlet and outlet Ø68mm WT EVO 3 Competition:Cooling surface 1890cm² / charge air volume 16,5LInlet and outlet Ø68mm Scope of delivery:1 intercooler together with the cross bar1 mounting material1 installation instruction1 TÜV parts certificate For racing only

€1,861.00

Intercooler Audi TTRS [8S] 2.5L Wagner Competition kit Evo 3.X voor upgrade 600PK+

WA200001136.X

€2,095.00

Intercooler Audi TTS [8J] 2.0 Wagner Competition kit Gen.2

WA200001034c

tts 8j 200kw/272HP (2008-2014) (not for engines with engine code CETA; CESA). The revised Competition Gen.2 intercooler kit for the VAG models with the 1st & 2nd generation 2.0T(F)SI engine. The Competition intercooler has the following net dimensions (610mm x 440mm x 65mm / 17.45L), providing a 10% larger flow area and 50% more intercooler volume compared to the original Audi S3 intercooler. The newly developed Competition high-performance mesh still grants enough airflow to the adjacent components, such as the water cooler, and is also very light (S3 OEM 8kg / WAGNERTUNING 9.2kg) . CAD developed freeform end boxes with incorporated cast aluminum air baffle for best possible internal air distribution.The CNC machined hose connections were enlarged to Ø67mm , so this kit comes with matching silicone hoses.Overall this intercooler has far from less back pressure than the stock cooler.In addition, all our intercoolers have an anti-corrosion coating with heat conduction properties. This guarantees optimal cooling with a significant increase in performance.Installation is done by replacing the OEM intercooler and is easy to perform.All our products are subject to constant qualitative monitoring.Available with TÜV parts certificate for many vehicles. The WAGNERTUNING Competition Intercooler Kit for the VAG 2,0TFSI / TSI engine is suitable for the following vehicles: ? Audi A3 8P 1,8 TFSI 118KW/160HP (2007-2012)? Audi A3 8P 2,0 TFSI 147KW/200HP (2004-2012)? Audi S3 8P 195KW/265HP (2006-2012)? Audi TT 8J 1.8 TSI 118KW/160HP (2008-2014)? Audi TT 8J 2,0 TFSI 147-155KW/200-211HP (2006-2014) (not MKB. CETA; CESA)? Audi TTS 8J 200KW/272HP (2008-2014) (not MKB. CETA; CESA) ? Volkswagen Golf 5 GTI (incl.ED 30) 147-169KW/200-230HP (2004-2008)? Volkswagen Golf 6 GTI (incl.ED 35) (Convertible) 155-173KW/211-235HP (2009-2013)? Volkswagen Golf 6 R (incl. Convertible) 199KW/270HP (2009-2013)? Volkswagen Scirocco 3 2,0 TSI 147-162KW/200-220HP (2008-2015)? Volkswagen Scirocco 3 R 195-206KW/265-280HP (2009-2015)? Volkswagen EOS 2.0 TFSI 147KW/200HP (2006-2009)? Volkswagen EOS 2.0 TFSI 155KW/211HP (2009-2014)? Volkswagen Jetta 5 2.0 TFSI 147KW/200HP (2005-2010)? Volkswagen Jetta 6 2.0 TSI 147-155KW/200-211HP (2010-2014)? Volkswagen Passat B6 1.8 TSI 118KW/160HP (2007-2010)? Volkswagen Passat B6 2.0 TSI 147KW/200HP (2005-2010)? Volkswagen Passat B7 1.8 TSI 118KW/160HP (2010-2012)? Volkswagen Passat B7 2.0 TSI 155KW/211HP (2010-2014)? Volkswagen Passat CC 1.8 TSI 118KW/160HP (2008-2012)? Volkswagen Passat CC 2.0 TFSI 147KW/200HP (2008-2010)? Volkswagen Passat CC 2.0 TSI 155KW/211HP (2010-2014)? Volkswagen Beetle 2.0 TSI 147-162KW/200-220HP (2011-) ? Skoda Octavia 1Z 1.8 TSI 118KW/160HP (2008-2013)? Skoda Octavia 1Z MK2 RS 147KW/200HP (2005-2009)? Skoda Octavia 1Z MK2 RS 155KW/211HP (2009-2013)? Skoda Suberb 3T 2.0 TSI 147KW/200HP (2010-2013) ? Seat Leon 1P 1,8 TFSI 118KW/160HP (2009-2012)* ? Seat Leon 1P 2,0 TFSI 136KW/185HP (2005-2006)* ? Seat Leon 1P FR 147KW/200HP (2006-2009)* ? Seat Leon 1P FR 155KW/211HP (2009-2012)* ? Seat Leon 1P Cupra 177KW/241HP (2007-2011)* ? Seat Leon 1P Cupra R 195KW/265HP (2009-2012)* ? Seat Leon 1P Copa Edition 210KW/286HP (2008)* ? Seat Leon 1P Cupra R310 LE 228KW/310HP (2009-2012)* ? Seat Leon 1P Cupra R310 WCE 228KW/310HP (2009-2012)* * slight modifications to the vehicle necessary Scope of delivery:1 intercooler2 silicone hoses4 hose clamps1 aluminum adapter1 assembly instruction

€996.00

Intercooler Audi TTS [8S] 2.0 TFSi Wagner Competition kit

WA200001048e

TTS [8S] 2.0 TFSI 228kw/310HP 2014- Please note ! necessary modifications: see supplied manual More power at the highest level COMPETITION INTERCOOLER KIT VAG 1.8 - 2.0TSI The Competition intercooler has the following net dimensions (640mm x 410mm x 65mm) and thus has 17 liters of external charge air volume (OEM 9 liters). The newly developed Competition high-performance mesh (Tube Fine) still provides sufficient airflow to the adjacent components, such as the water cooler, and is also very light. The intercooler has a total weight of only 8.9kg. The cast aluminum end boxes were created in CAD and optimized for the best possible internal airflow using CFD simulations. An air guide integrated in the end box allows a homogeneous filling of the Competition high performance mesh. The intercooler's inlets and outlets were enlarged to Ø 70mm, so this kit comes with reinforced silicone hoses. Overall, this intercooler has far less back pressure than the stock intercooler. In addition, all our intercoolers have an anti-corrosion coating with heat conduction properties. This guarantees permanent and optimal cooling with a significant increase in performance. The assembly is done by replacing the OEM intercooler and is easy to perform. All our products are subject to constant qualitative monitoring. The WAGNERTUNING Competition intercooler kit for the VAG 1,8TSI - 2,0TSI engine is suitable for the following vehicles: - VW Golf 7+7.5 GTI 2,0 TSI 162-228KW/220-310HP (incl. Facelift- Performance and Clubsport[S] models)- VW Golf 7+7.5 R 2,0 TSI 221-228KW/300-310HP (incl. Facelift models)- VW Arteon 2,0 TSI 140-206KW/190-280HP- Skoda Superb 3V 2,0TSI 162KW/220HP- Skoda Superb 3V 2,0TSI 206KW/280HP With further modifications (see notes) on the vehicle, also suitable for:- Audi A3 8V 1,8TSI 132KW/180HP*- Audi A3 8V 2,0TSI 140KW/190HP*- Audi S3 8V 2,0TSI 221-228KW/300-310HP*- Audi TT 8S 2.0TFSI 169KW/230HP*- Audi TTS 8S 2,0TSI 228KW/310HP*- Seat Leon 5F Cupra 2,0TSI 195-272KW/265-370HP* (incl. Cupra ST 265-370 & Cupra R)- Skoda Octavia 5E 1,8TSI 132KW/180HP* (incl. Cupra ST 265-370/265-370HP*)- Skoda Octavia 5E RS 2,0TSI 162-180KW/220-245HP* (incl. Cupra ST 265-370HP*) Due to the additional adjustments, the installation effort increases to a total of approx. 5-6hrs: Scope of delivery:1 intercooler2 silicone hoses2 hose clamps1 mounting material1 assembly instruction

€996.00
