4.2 V8 352W/480HP 2004- Volume: 2x6.15L (98% more volume)Weight: 2x6.2kg (For all RS6 models with auxiliary water cooler behind the intercoolers) The high performance intercoolers have the following net dimensions (255x230x105), providing a 39% larger flow area, as well as 98% more charge air volume compared to the original intercooler. The newly developed Competition high-performance mesh offers the highest cooling characteristics at the cutting edge of tube-fin technology. The end boxes of the intercooler are made of cast aluminum and were optimized using flow analyses in the CAD system. The intercooler kit was developed directly for the RS6 C5. An optimal cooling of the charged air with a significant increase in performance!This kit also includes air guides made of visually appealing carbon. The installation is done at the original mounting points and is very easy to perform. All our products are subject to constant qualitative monitoring. Scope of delivery:2 intercoolers (right, left)1 bracket for the auxiliary water cooler1 mounting material1 Mounting Material

RS3 2.5 RS TFSI 228/250/270kw/310/340/367HP (2013-) Volume: 15.6LWeight: 11.2kg The high performance intercooler has the following mesh dimensions (600mm x 260mm x 100mm), providing 87% larger flow area and 70% more charge air volume compared to the original intercooler. The newly developed Competition high-performance mesh grants sufficient airflow to the adjacent components, such as the water cooler, and is also very lightweight. The end boxes of the charge air cooler are made of cast aluminum and were optimized under flow analyses in the CAD system. With the help of incorporated air baffles, in the entrance, a uniform filling of the intercooler is ensured. The result is excellent cooling properties with low back pressure. Thus, this kit is exactly the right thing for racing. The intercooler and the original crossmember form a stable unit and weighs only 11.2kg thanks to the new Competition high-performance mesh. The assembly is done at the original mounting points and is easy to perform(1:1 exchange). An optimal cooling of the charged air with a significant increase in power! 66mm inlet and outlet. OEM intercooler: cooling surface 832cm² / charge air volume 9,15LWT EVO 2 Competition: cooling surface 1560cm² / charge air volume 15,6L All our products are subject to constant qualitative monitoring. Scope of delivery:1 intercooler together with the cross bar1 mounting material1 installation instruction   Remark: only for racing

Audi RSQ3 F3 294KW/400HP 10/2019+ Competition's high-performance intercooler has the following net dimensions (660x180x110 = 13,070cm³) and thus offers a 14% larger intake area and 57% more charge air volume compared to the original intercooler. Competition's high-quality mesh is a high-performance tubular fin with internal turbulators. Despite its size, the total weight of the intercooler is only 8.3 kg. The end tanks of the intercooler are cast aluminum and were optimized using flow analysis in the CFD system. The result is excellent cooling properties with minimal back pressure. In addition, all our charge air coolers have a corrosion-resistant coating with heat-conducting properties. This guarantees permanent and optimal cooling with a significant performance increase. Fully installation-ready kit, simply replace with series intercooler - plug and play. Tested and pressure stable up to 6 bar. All our products are under constant quality control. Suitable for racing. Dimensions original intercooler:640mm x 163mm x 80mmV=8.3 literA=1043 cm² Dimensions WAGNERTUNING intercooler:660mm x 180mm x 110mmV=13.07 literA=1188 cm² Scope of delivery:1 intercooler (black coated)1 mounting instruction

Audi RSQ3 F3 294KW/400HP 10/2019+ The high performance intercooler has the following mesh dimensions (515mm x 367mm x 95mm [stepped] = 16,500cm³), providing 84% more flow area, as well as 101% more charge air volume compared to the original intercooler. The newly developed Competition high-performance network grants sufficient airflow to the adjacent components, such as the water cooler. It is a high quality Tube Fin net with internal turbulators. The end boxes of the charge air cooler are made of cast aluminum and were optimized under flow analyses in the CFD system. With the help of incorporated air baffles, in the inlet, a uniform filling of the intercooler is ensured. The result is excellent cooling properties with minimal back pressure. Thus, this kit is suitable for racing. In addition, all our intercoolers have an anti-corrosion coating with heat conduction properties. This guarantees permanent and optimal cooling with a significant increase in performance. The intercooler and the original crossmember form a stable unit and weighs, thanks to the new Competition high-performance mesh, only 11.7kg. The installation is done at the original mounting points and is easy to perform (see installation instructions for slight adjustments). Tested and pressure stable up to 6 bar. All our products are subject to constant qualitative monitoring. OEM intercooler:Cooling surface 1024cm² / charge air volume 8,2LInlet and outlet Ø68mm WT EVO 3 Competition:Cooling surface 1890cm² / charge air volume 16,5LInlet and outlet Ø68mm Scope of delivery:1 intercooler together with the cross bar1 mounting material

2.0 TSI 170kw/231hp 2014-. The Competition high performance intercooler has the following mesh dimensions (620mm x 175mm x 110mm/stepped = 10,100cc), providing a 44% larger flow area and 68% more charge air volume compared to the original intercooler. The Competition high-performance mesh offers very good cooling properties. CAD designed free-form cast aluminum end boxes for best possible internal airflow. Overall, this intercooler has much less back pressure than the stock intercooler. In addition, all our intercoolers have an anti-corrosion coating with heat conduction properties. This guarantees optimum cooling with a significant increase in performance. Complete ready-to-install kit, simply replace with stock intercooler - plug and play. Tested up to 6 bar and pressure stable. All our products are subject to constant qualitative monitoring. Suitable for racing. 60mm inlet and outlet. Scope of delivery:1 intercooler1 mounting material1 installation instructions

2.2L 162-169KW - 220-230 HP Volume: 8.7LWeight: 8.0 kg The high performance intercooler has the following net dimensions (500mm x 205mm x 85mm), offering a 10% larger flow area, as well as 45% more intercooler volume compared to the original RS 2 intercooler. The newly developed Competition high-performance mesh offers the highest cooling characteristics on the latest Tube-Fin technology. The end boxes of the intercooler are made of cast aluminum and were optimized using flow analyses in the CAD system. The intercooler kit was developed directly for the S2/RS2. An optimal cooling of the charged air with a significant increase in performance!The assembly is done by replacing the OEM intercooler and is easy to perform. All our products are subject to constant qualitative monitoring. Scope of delivery:1 Intercooler EVO1 Gen.21 Stainless steel adapter for Audi S2/RS2 crossmember1 mounting material *) in combination with adjacent RS2 technology Translated with www.DeepL.com/Translator (free version)

2.2L 162-169KW - 220-230 HP Volume: 9.9LWeight: 8.0kg Version for short WAGNER intake manifold 160001001 The high performance intercooler has the following net dimensions (500mm x 220mm x 90mm V=9.9Liter), offering an 18% larger flow area, as well as 65% more intercooler volume compared to the original RS 2 intercooler. The newly developed Competition high-performance mesh offers the highest cooling characteristics at the cutting edge of tube-fin technology. The end boxes of the intercooler are made of cast aluminum and were optimized using flow analyses in the CAD system. The intercooler kit was developed directly for the S2/RS2 in conjunction with our short intake manifold. The installation is done by replacing the OEM intercooler and is easy to do. An optimal cooling of the supercharged air with a significant increase in performance! Intercooler EVO2 Gen.2 WAGNER S2/RS2Stainless steel cross barPiping for additional air slideSilicone hose from LLK to throttle valveSilicone adapter 50/70mm LLK inletSilicone hose for auxiliary water coolerMounting material

2.2L 162-169KW - 220-230HP Version for S2/RS2 with short intake tubeIntercooler mesh dimensions: 500x220x90This is the intercooler from kit 200001014

S3 [8L] 1.8T 1999-2001 154KW/210HP (APY, AMK, AUL)S3 [8L] 1.8T 2001-2003 165KW/225HP (BAM) Volume: 10.65LWeight: 9.7kg Maximum cooling of the charge air.More power through improved performance cooling network.The air header is made of cast aluminum (CAD optimized) and is extremely pressure resistant.60mm inlet/70mm outlet (ideal for larger throttle bodies).Plug & Play. No adjustment work necessary. Intercooler is mounted before the original water and air conditioning package. The high performance intercooler has the following net dimensions 600 x 355 x50, 10.650cm³ volume. An optimal cooling of the charged air with a significant increase in power!Original intercooler: 2pcs. 174mm x 183mm x 85mm, 2.700cm³ Scope of delivery:1 intercooler2 silicone hoses4 hose clamps1 mounting material1 assembly instruction

2.0 195KW/265HP 2006-2012 Volume: 17.4LWeight: 9.3kg The revised Competition Gen.2 intercooler kit for the VAG models with the 1st & 2nd generation 2.0T(F)SI engine. The Competition intercooler has the following net dimensions (610mm x 440mm x 65mm / 17.45L), providing a 10% larger flow area and 50% more intercooler volume compared to the original Audi S3 intercooler. The newly developed Competition high-performance mesh still grants enough airflow to the adjacent components, such as the water cooler, and is also very light (S3 OEM 8kg / WAGNERTUNING 9.2kg) . CAD developed freeform end boxes with incorporated cast aluminum air baffle for best possible internal air distribution.The CNC machined hose connections were enlarged to Ø67mm , so this kit comes with matching silicone hoses.Overall this intercooler has far from less back pressure than the stock cooler.In addition, all our intercoolers have an anti-corrosion coating with heat conduction properties. This guarantees optimal cooling with a significant increase in performance.Installation is done by replacing the OEM intercooler and is easy to perform.All our products are subject to constant qualitative monitoring.Available with TÜV parts certificate for many vehicles. The WAGNERTUNING Competition intercooler kit for the VAG 2,0TFSI / TSI engine is suitable for the following vehicles: ? Audi A3 8P 1,8 TFSI 118KW/160HP (2007-2012)? Audi A3 8P 2,0 TFSI 147KW/200HP (2004-2012)? Audi S3 8P 195KW/265HP (2006-2012)? Audi TT 8J 1.8 TSI 118KW/160HP (2008-2014)? Audi TT 8J 2,0 TFSI 147-155KW/200-211HP (2006-2014) (not MKB. CETA; CESA)? Audi TTS 8J 200KW/272HP (2008-2014) (not MKB. CETA; CESA) ? Volkswagen Golf 5 GTI (incl.ED 30) 147-169KW/200-230HP (2004-2008)? Volkswagen Golf 6 GTI (incl.ED 35) (Convertible) 155-173KW/211-235HP (2009-2013)? Volkswagen Golf 6 R (incl. Convertible) 199KW/270HP (2009-2013)? Volkswagen Scirocco 3 2.0 TSI 147-162KW/200-220HP (2008-2015)? Volkswagen Scirocco 3 R 195-206KW/265-280HP (2009-2015)? Volkswagen EOS 2.0 TFSI 147KW/200HP (2006-2009)? Volkswagen EOS 2.0 TFSI 155KW/211HP (2009-2014)? Volkswagen Jetta 5 2.0 TFSI 147KW/200HP (2005-2010)? Volkswagen Jetta 6 2.0 TSI 147-155KW/200-211HP (2010-2014)? Volkswagen Passat B6 1.8 TSI 118KW/160HP (2007-2010)? Volkswagen Passat B6 2.0 TSI 147KW/200HP (2005-2010)? Volkswagen Passat B7 1.8 TSI 118KW/160HP (2010-2012)? Volkswagen Passat B7 2.0 TSI 155KW/211HP (2010-2014)? Volkswagen Passat CC 1.8 TSI 188KW/160HP (2008-2012)? Volkswagen Passat CC 2.0 TFSI 147KW/200HP (2008-2010)? Volkswagen Passat CC 2.0 TSI 155KW/211HP (2010-2014)? Volkswagen Beetle 2.0 TSI 147-162KW/200-220HP (2011-) ? Skoda Octavia 1Z 1,8 TSI 118KW/160HP (2008-2013)? Skoda Octavia 1Z MK2 RS 147KW/200HP (2005-2009)? Skoda Octavia 1Z MK2 RS 155KW/211HP (2009-2013)? Skoda Suberb 3T 2.0 TSI 147KW/200HP (2010-2013) ? Seat Leon 1P 1,8 TFSI 118KW/160HP (2009-2012)* ?? Seat Leon 1P 2,0 TFSI 136KW/185HP (2005-2006)* ?? Seat Leon 1P FR 147KW/200HP (2006-2009)* ?? Seat Leon 1P FR 155KW/211HP (2009-2012)* ?? Seat Leon 1P Cupra 177KW/241HP (2007-2011)* ?? Seat Leon 1P Cupra R 195KW/265HP (2009-2012)* ?? Seat Leon 1P Copa Edition 210KW/286HP (2008)* ?? Seat Leon 1P Cupra R310 LE 228KW/310HP (2009-2012)* ?? Seat Leon 1P Cupra R310 WCE 228KW/310HP (2009-2012)* ? * slight modifications to the vehicle necessary Scope of delivery:1 intercooler2 silicone hoses4 hose clamps1 aluminum adapter1 assembly instruction

The Competition intercooler has the following net dimensions (640mm x 410mm x 65mm) and thus has 17 liters of external charge air volume (OEM 9 liters). The newly developed Competition high-performance mesh (Tube Fine) grants the adjacent components, such as the water cooler, still enough air flow and is also very light. The intercooler has a total weight of only 8.9kg. The cast aluminum end boxes were created in CAD and optimized for the best possible internal airflow using CFD simulations. An air guide integrated in the end box allows a homogeneous filling of the Competition high performance mesh. The intercooler's inlets and outlets were enlarged to Ø 70mm, so this kit comes with reinforced silicone hoses. Overall, this intercooler has far less back pressure than the stock intercooler. In addition, all our intercoolers have an anti-corrosion coating with heat conduction properties. This guarantees permanent and optimal cooling with a significant increase in performance. The assembly is done by replacing the OEM intercooler and is easy to perform. All our products are subject to constant qualitative monitoring.   The WAGNERTUNING Competition intercooler kit for the VAG 1,8TSI - 2,0TSI engine is suitable for the following vehicles: - VW Golf 7+7.5 GTI 2,0 TSI 162-228KW/220-310HP (incl. Facelift- Performance and Clubsport[S] models)- VW Golf 7+7.5 R 2,0 TSI 221-228KW/300-310HP (incl. Facelift models)- VW Arteon 2,0 TSI 140-206KW/190-280HP- Skoda Superb 3V 2,0TSI 162KW/220HP- Skoda Superb 3V 2,0TSI 206KW/280HP With further modifications (see notes) on the vehicle, also suitable for:- Audi A3 8V 1,8TSI 132KW/180HP*- Audi A3 8V 2,0TSI 140KW/190HP*- Audi S3 8V 2,0TSI 221-228KW/300-310HP*- Audi TT 8S 2.0TFSI 169KW/230HP*- Audi TTS 8S 2.0TSI 228KW/310HP*- Seat Leon 5F Cupra 2,0TSI 195-272KW/265-370HP* (incl. Cupra ST 265-370 & Cupra R)- Skoda Octavia 5E 1,8TSI 132KW/180HP* (incl. Cupra ST 265-370/265-370PS*)- Skoda Octavia 5E RS 2,0TSI 162-180KW/220-245HP* (incl. Cupra ST 265-370PS*) Due to the additional adjustments, the installation effort increases to a total of approx. 5-6hrs: Scope of delivery:1 intercooler2 silicone hoses2 hose clamps1 mounting material1 assembly instruction

Fits the following models: Audi S4 [B5] 2.7 Biturbo 195KW/265HP 1997-2001Audi A6 [C5] 2.7 Biturbo 169-184KW/230-250HP 1997-2005 Notes:May require modification for A6 2.7T V6 with automatic transmission Information:Volume: 2x4.25L (90% more cargo volume)Weight: 2x4.2kg Packaging:2x Intercooler (left/right) 220x215x901x mounting materialAssembly manual

Fits the following models: Audi S4 [B5] 2.7 Biturbo 195KW/265HP 1997-2001Audi A6 [C5] 2.7 Biturbo 169-184KW/230-250HP 1997-2005 Information:Volume: 2x4.25L (90% more cargo volume)Weight: 2x4.2kg Packing:2x Intercooler (left/right) 220x215x902x carbon air guide (left/right)1x mounting materialAssembly manual

Audi S4 B9 3.0TFSI 260KW/354HP (2016+)Audi S5 F5 3,0TFSI 260KW/354HP (2016+) The Competition high performance intercooler has the following net dimensions (550mm x 445mm x 70mm = 17,130cm³), offering a 134% larger flow area, as well as 105% more charge air volume compared to the original intercooler. The Competition high performance mesh is a high quality Tube Fin mesh with internal turbulators. Despite its size, the total weight of the intercooler is only 9.5kg. The end boxes of the intercooler are made of cast aluminum and have been optimized using flow analysis in the CFD system.The connection diameters are Ø62mm at the intercooler inlet and Ø67mm at the intercooler outlet. Optionally, this kit is available with complete charge air piping. This includes 3 reinforced silicone hoses, as well as 1 aluminum charge air pipe.The result is excellent cooling characteristics with the lowest back pressure. In addition, all our intercoolers have an anti-corrosion coating with heat conduction properties. This guarantees long-lasting and optimum cooling with a significant increase in performance. Complete ready-to-install kit, simply replace with stock intercooler - plug and play. Tested and pressure stable up to 6 bar. All our products are subject to constant qualitative monitoring. Suitable for racing. Dimensions original intercooler:720mm x 145mm x 80mmV=8,35 LiterA=1044 cm² Dimensions WAGNERTUNING intercooler:550mm x 445mm x 70mmV=17,13 LiterA=2447 cm² Scope of delivery:1 intercooler (black coated)1 aluminum charge air pipe (black coated) / optional 3 reinforced silicone hoses (black) / optional 1 mounting material

Audi S4 B9 3.0TFSI 260KW/354HP (2016+)Audi S5 F5 3,0TFSI 260KW/354HP (2016+) The Competition high performance intercooler has the following net dimensions (550mm x 445mm x 70mm = 17,130cm³), offering a 134% larger flow area, as well as 105% more charge air volume compared to the original intercooler. The Competition high performance mesh is a high quality Tube Fin mesh with internal turbulators. Despite its size, the total weight of the intercooler is only 9.5kg. The end boxes of the intercooler are made of cast aluminum and have been optimized using flow analysis in the CFD system.The connection diameters are Ø62mm at the intercooler inlet and Ø67mm at the intercooler outlet. Optionally, this kit is available with complete charge air piping. This includes 3 reinforced silicone hoses, as well as 1 aluminum charge air pipe.The result is excellent cooling characteristics with the lowest back pressure. In addition, all our intercoolers have an anti-corrosion coating with heat conduction properties. This guarantees long-lasting and optimum cooling with a significant increase in performance. Complete ready-to-install kit, simply replace with stock intercooler - plug and play. Tested and pressure stable up to 6 bar. All our products are subject to constant qualitative monitoring. Suitable for racing. Dimensions original intercooler:720mm x 145mm x 80mmV=8,35 LiterA=1044 cm² Dimensions WAGNERTUNING intercooler:550mm x 445mm x 70mmV=17,13 LiterA=2447 cm² Scope of delivery:1 intercooler (black coated)1 aluminum charge air pipe (black coated) / optional 3 reinforced silicone hoses (black) / optional 1 mounting material

Audi S4 B9 3.0TFSI 260KW/354HP (2016+)Audi S5 F5 3,0TFSI 260KW/354HP (2016+) The Competition high performance intercooler has the following net dimensions (550mm x 445mm x 70mm = 17,130cm³), offering a 134% larger flow area, as well as 105% more charge air volume compared to the original intercooler. The Competition high performance mesh is a high quality Tube Fin mesh with internal turbulators. Despite its size, the total weight of the intercooler is only 9.5kg. The end boxes of the intercooler are made of cast aluminum and have been optimized using flow analysis in the CFD system.The connection diameters are Ø62mm at the intercooler inlet and Ø67mm at the intercooler outlet. Optionally, this kit is available with complete charge air piping. This includes 3 reinforced silicone hoses, as well as 1 aluminum charge air pipe.The result is excellent cooling characteristics with the lowest back pressure. In addition, all our intercoolers have an anti-corrosion coating with heat conduction properties. This guarantees long-lasting and optimum cooling with a significant increase in performance. Complete ready-to-install kit, simply replace with stock intercooler - plug and play. Tested and pressure stable up to 6 bar. All our products are subject to constant qualitative monitoring. Suitable for racing. Dimensions original intercooler:720mm x 145mm x 80mmV=8,35 LiterA=1044 cm² Dimensions WAGNERTUNING intercooler:550mm x 445mm x 70mmV=17,13 LiterA=2447 cm² Scope of delivery:1 intercooler (black coated)1 aluminum charge air pipe (black coated) / optional 3 reinforced silicone hoses (black) / optional 1 mounting material

Audi S4 B9 3.0TFSI 260KW/354HP (2016+)Audi S5 F5 3,0TFSI 260KW/354HP (2016+) The Competition high performance intercooler has the following net dimensions (550mm x 445mm x 70mm = 17,130cm³), offering a 134% larger flow area, as well as 105% more charge air volume compared to the original intercooler. The Competition high performance mesh is a high quality Tube Fin mesh with internal turbulators. Despite its size, the total weight of the intercooler is only 9.5kg. The end boxes of the intercooler are made of cast aluminum and have been optimized using flow analysis in the CFD system.The connection diameters are Ø62mm at the intercooler inlet and Ø67mm at the intercooler outlet. Optionally, this kit is available with complete charge air piping. This includes 3 reinforced silicone hoses, as well as 1 aluminum charge air pipe.The result is excellent cooling characteristics with the lowest back pressure. In addition, all our intercoolers have an anti-corrosion coating with heat conduction properties. This guarantees long-lasting and optimum cooling with a significant increase in performance. Complete ready-to-install kit, simply replace with stock intercooler - plug and play. Tested and pressure stable up to 6 bar. All our products are subject to constant qualitative monitoring. Suitable for racing. Dimensions original intercooler:720mm x 145mm x 80mmV=8,35 LiterA=1044 cm² Dimensions WAGNERTUNING intercooler:550mm x 445mm x 70mmV=17,13 LiterA=2447 cm² Scope of delivery:1 intercooler (black coated)1 aluminum charge air pipe (black coated) / optional 3 reinforced silicone hoses (black) / optional 1 mounting material
